A 16” fan with the performance of a 20”: compact and powerful.

Product details

The BATFAN M, powered by Milwaukee® M18 batteries, delivers the optimal ratio between portability and performance. Compact, lightweight, and durable, it is designed to meet the demanding needs of firefighter operations.

With an AMCA airflow of up to 16,502 m³/h and a 48-minute runtime using two 12Ah batteries, this fan ensures consistent and reliable efficiency.

Thanks to its versatility and modularity, it operates with one or two batteries without any loss of performance, providing great flexibility for various applications, including PPV, combined PPV, and extraction.

Its Milwaukee® compliance guarantees high-quality performance, while its resistance to extreme conditions (up to 50°C) enhances firefighter safety.

The BATFAN M was developed in close collaboration with Milwaukee USA, ensuring perfect compatibility with Milwaukee® M18 batteries. Battery performance is monitored during discharge, preserving efficiency while maintaining system reliability.

Technical specification

Open air flow
24 102 m³/h
AMCA 240 flow rate
16 502 m³/h
Weight 21.8 kg with 2 x 12Ah batteries
18.7 kg without battery
Dimensions W x H x D
Folded: 540 x 530 x 270 mm
Propeller diameter
420 mm
Autonomy 48 min with 2 batteries 12Ah Milwaukee
24 min with 1 battery
Operating temperature Up to +50°C
Engine 280W
Power supply
Interchangeable Li-ion battery or mains supply
IP
IP X6 (batteries connected)
Noise level
79 dB at 3m
Ventilation type
PPV, combined PPV and Extraction
Garantees
BATFAN M 5 years / engine 3 years / battery (Milwaukee guarantee)
